20ft Skeleton Double-trailer with Two-axle
The trailer is designed for stevedoring and transporting loose cargos.
Dimension:
Length: Approx 13,284mm
Width: Approx 2,480mm
Height: According to customer’s choice
King Pin Location: Front: Approx 500mm from the front face of the front bolster
Rear: Approx 500mm from the front face of the front bolster
Axle spacer: Front: Approx 6154mm+1310mm
Rear: Approx 3460mm+1310mm
King Pin Height: According to prime mover
(The above dimension will be adjusted according to the tractor specification. )
Weight:.
Tare Weight (Tolerance 0~-4%): Front: Approx 4,000 kg
Rear: Approx 3,500 kg
Max. Payload: Approx 60,000kg in total
Gross Vehicle Weight: Approx 77,500 kg
Steel Structure:
Material: High strength low alloy steel with (Q345) 350 MPa yield strength is used for welded I-beam and (Q235) 235 MPa yield strength is used for the fabricated parts .
OEM Parts Configuration:
King Pin: 2” or 3.5” bolting king pin. Brand: JOST. One for each trailer.
Landing Gear: 2 speed road side winding with sand shoe, Type: GOLDEN STONE. Static Lifting capacity 80T. 2 units
Suspension: American type Under Mount mechanical suspension with 8 leaf spring(90mm width, 16mm thickness).
Axles: Fuwa 13 tons capacity. 2 axles for front, 2 axles for rear.
Rims: 8.25-22.5, 10 Holes ISO,17 pieces
Tires: 11R22.5, 17 pieces, Chinese famous brand , choose by the factory.
Brake System: Dual air brake system, WABCO relay emergency valve, with ABS system.
Brake chamber: Type 30/30 on both two axles.
Electrical System: 24 volt lighting system with modular wiring harness,7 way ISO receptacle infront of the front bolster. Chinese standard . No E-mark and SAE certificate.
Others:
Spare Tire Carrier: Equipped two sets per chassis with one spare tire.
Side Guard:Standard
Tool Box: Equipped one set for each
Painting: colored by customer’s request
